ECS A780LM-M2

Spesifikasi CPU Socket Socket AM3 Supported CPU AMD Phenomâ „ ¢ II / Athlonâ „ ¢ / Sempron processors ( TDP max 125W) Northbridge Chipset AMDÂ ® 760G Southbridge Chipset AMDÂ ® SB710 Front Side Bus HyperTransport 3.0 DIMM Sockets 2 x 240-pin DDR3 DIMM Supported Memory Support DDR3 up to 1800( OC) / 1600( OC) / 1333/ 1066 DDR3 SDRAM Max. Memory 8 GB Expansion Slots * 1 x PCI Express x16 slot * 1 x PCI Express x1 slot * 1 2 x PCI slots Serial ATA Controller 4 x Serial ATA 3.0Gb/ s devices Supported RAID RAID0, RAID1, RAID10 Audio VIAÂ ® VT1705 6-channel audio CODEC LAN Realtek 8105E 10/ 100 Lan USB USB 2.0 BIOS AMI BIOS with 8Mb SPI Flash ROM Internal I/ O * 1 x 24-pin ATX Power Supply connector * 1 x 4-pin 12V Connector * 1 x 4-pin CPU_ FAN connector * 1 x 3-pin SYS_ FAN connector * 1 x IDE connector * 1 x Front panel switch/ LED header * 1 x Front panel audio header * 1 x Clear CMOS header * 1 x Serial port header * 1 x Parallel Header * 4 x SATA 3Gb/ s connectors * 2 x USB 2.0 headers support additional 4 USB 2.0 Ports * 1 x Chassis intrusion header External I/ O * 1 x PS/ 2 Keyboard & PS/ 2 mouse connectors * 1 x D-sub ( VGA) * 1 x DVI connector ( optional) * 1 x RJ45 LAN connector * 1 x Audio port ( Line-in, Line-out, Mic-in) * 4 x USB 2.0 Ports Form Factor Micro-ATX Dimensi 244 x 180 mm
